Lockout Boxes

Best Price & Quality Guaranteed.

We have the widest selection of Lockout Boxes, with rapid delivery times, in the UK, Europe, Middle East, USA, South America and Russia.

WHY LOCKOUT TAGOUT?

Every year thousands of workers get killed or injured while performing repairs or maintenance on industrial equipment or machinery. Many of these accidents are caused by the uncontrolled release of energy. Our lockout/tagout products and services, offers a broad range of durable, easy-to-use lockout devices that cover most mechanical and electrical applications. Lockout Tagout Safety services help companies with limited resources quickly get their program up to speed, ensuring that lockout activities are implemented in a way that promotes optimum safety while maximizing efficiency and reducing downtime.

Contact Us

Lockout Tagout Safety Ltd
4D Brighouse Road,
River Court, Middlesbrough,
TS2 1RT

Phone 01642 244017

Email Us Today



Request Quote / Email



Site Surveys







ISO9002



Lockout Stations



Lockout kits Site



Electrical Lockout Site



Mechanical Safety Website



Legislation

Industrial Plant Safety Workshops

Safety Catalogue

Request Quote / Email

Request Quote















Multilock images



Request a quote call us









Mini Circuit Breaker Lockout Devices



Pipe Marking

Lockout Boxes

Safety group lockout boxes are designed to hold lockout equipment in a central location making access to isolating equipment easy. Secure each lockout point on one or more large items of equipment using your personal lockout padlock. Having locked the equipment, secure your keys in the lockout box. Each person working on the equipment attaches their own personal padlock to the box for the duration of the operation and only removes it once the operation is complete. This ensures that no one can access the keys inside the box until every member of the group has removed their padlock.

Ideal for shift work with staggered hours or for subcontracted operations, these boxes reduce the number of padlocks required for lockout. An ideal solution for a company with a larger sized lockout-tagout protocol. Built for the toughest conditions, they are made of double moulded polystyrene and come complete with metal or plastic hanging hooks for padlocks and lockout hasps.

Our full range is available on our website, www.lockout-tagout.co.uk

Dual Application Group Lock Box

KLICKER-MF High Security cable Seals

Features:-

  • Dimensions : 324 x 89 x 162mm
  • Exclusive Latch Tight locking mechanism that prevents keys from being accessed until last padlock or lockout hasp is removed from the box. Provides the highest level of security available in a group lock box
  • Durable powder coated finish with stainless steel handle
  • Portable solution so it can be carried from job to job or can be mounted on a wall
  • Available in Red & Yellow
  • Accepts 14 padlocks or lockout hasps which means more padlocks can be attached
  • Secure each lockout point on a piece of equipment with a single padlock. Place the keys in the group lock box and then each authorised employee places their personal padlock on the lock box
  • When work is complete, employees take their personal padlocks off the lock box, freeing the keys inside. Keys inside can not be accessed until the last employee removes their padlock.
3.5mm Midi Cable Lock Seal (Car Seal) Pack 10

Features:-

  • Model GL1 Steel Group Lockout Tagout Box
  • Holds 8 keys inside the lockout box
  • Wide- 12"  Height- 11"  Depth- 3"
  • Number of lock holes- 10
  • Case and hooks are constructed of steel for long-lasting durability
  • Optional carrying handle allows for either portable or stationary use
  • Durable red powder paint is used on the lockout box and handle. Key holders are painted white
  • Clear acrylic window provides good visibility of keys and tags

GL1/2 - Key Group Lockout Box

Tool Cable Seals

Features:-

  • Model GL1/2 Steel Group Lockout Tagout Box
  • Holds 4 keys inside the lockout box
  • Wide- 6"  Height- 10"  Depth- 3"
  • Number of lock holes- 5
  • Case and hooks are constructed of steel for long-lasting durability
  • Optional carrying handle allows for either portable or stationary use
  • Durable red powder paint is used on the lockout box and handle. Key holders are painted white
  • Clear acrylic window provides good visibility of keys and tags

GL2 - Key Group Lockout Box

Container Bolt Lock

Features:-

  • Model GL2 Steel Group Lockout Tagout Box
  • Holds 24 keys inside the lockout box
  • Wide- 12 1/2"  Height- 17 1/2"  Depth- 3"
  • Number of lock holes- 10
  • Case and hooks are constructed of steel for long-lasting durability
  • Optional carrying handle allows for either portable or stationary use
  • Durable red powder paint is used on the lockout box and handle. Key holders are painted white
  • Clear acrylic window provides good visibility of keys and tags

GL3 - Key Group Lockout Box

DOMINOSP-MF Indicative Seals



Features:-

  • Model GL3 Steel Group Lockout Tagout Box
  • Holds 50 keys inside the lockout box
  • Wide- 18 1/8"  Height- 20"  Depth- 3"
  • Number of lock holes- 25
  • Case and hooks are constructed of steel for long-lasting durability
  • Optional carrying handle allows for either portable or stationary use
  • Durable red powder paint is used on the lockout box and handle. Key holders are painted white
  • Clear acrylic window provides good visibility of keys and tag

002710-KW Type 1 Lockout Box

DRAGONWP-MF Indicative Seals

Features:-

  • Type 1 Key Safe measures 150mm wide x 200mm high x 105mm deep
  • Constructed from 1.3mm mild steel and powder coated to BS361 Grey.
  • 4 unique secondary locks, marked A, B, C, D and a central control lock.
  • Stainless steel hinge wire is extended to form a key bar, the free end of the key bar is trapped when the safe door is locked.
  • 2 loose mounted internal shelves, equally spaced within the key safe.
  • Two 6.5mm keyhole type fixing slots are provided in the back plate of the unit for wall mounting.
  • The clear window in the door is made from 3mm acrylic, which is designed to permit entry to the safe by breaking, in case of emergency.
  • All secondary locks are unique and are supplied complete with a brass tag, engraved with the key safe number and secondary lock identification.

002721-KW Type 2 Lockout Box

FASTSEAL-MF Indicative Seals

Features:-

  • Type 2 Key Safe measures 150mm wide x 230mm high x 105mm deep
  • Constructed from 1.3mm mild steel and powder coated to BS361 Grey.
  • 7 unique secondary locks, marked A, B, C, D, E, F, G and a central control lock.
  • Stainless steel hinge wire is extended to form a key bar, the free end of the key bar is trapped when the safe door is locked.
  • 2 loose mounted internal shelves, equally spaced within the key safe.
  • Two 6.5mm keyhole type fixing slots are provided in the back plate of the unit for wall mounting.
  • The clear window in the door is made from 3mm acrylic, which is designed to permit entry to the safe by breaking, in case of emergency.
  • All secondary locks are unique and are supplied complete with a brass tag, engraved with the key safe number and secondary lock identification.
FASTSEAL-MF Indicative Seals

Features:-

  • Dimensions : 152 x 235 x 95 mm
  • Exclusive Latch Tight locking mechanism that prevents keys from being accessed until last padlock or lockout hasp is removed from the box. Provides the highest level of security available in a group lockout box
  • Durable powder coated finish with stainless steel handle
  • Portable solution.
  • Available in Red
  • Accepts 12 padlocks or lockout hasps which means more padlocks can be attached
  • Secure each lockout point on a piece of equipment with a single padlock. Place the keys in the group lock box and then each authorised employee places their personal padlock on the lock box
  • When work is complete, employees take their personal padlocks off the lock box, freeing the keys inside. Keys inside can not be accessed until the last employee removes their padlock.
